性能特點  Performance Features

◆ 采用高強度機身構造，變形量小，精度高。
◆ 滑塊采用四角八面導路，可承載較大的偏心負載，確保沖壓精度的長期、穩定保持。
◆ 滑塊導軌采用“高頻淬火”十 “導軌研磨工藝”，磨損小、精度高、精度保持時間長、提高模具使用壽命。
◆ 采用強制稀油循環潤滑裝置：節能、環保、設有自動報警功能，具有更好的流行性及散熱性，潤滑效果更好。
◆ 曲軸采用高強度合金材質42CrMo，強度比45鋼提高了1.3倍，使用壽命更長。
◆ 銅套采用錫磷青銅ZQSn10-1，強度比普通BC6黃銅提高了1.5倍采用高靈敏液壓過載保護裝置，可有效保護沖床和模具使用壽命。
◆ 標配日本SMC調壓閥、油霧器、空氣過濾器。
◆ 標配觸摸屏、西門子電機。
◆ 可選配模墊（氣墊）。

◆ Adopting high-strength body structure, with small deformation and high accuracy.
◆ The slider adopts a four corner and eight sided guide path, which can bear large eccentric loads, ensuring long-term and stable maintenance of stamping accuracy.
◆ The slide rail adopts the "high-frequency quenching" and "rail grinding process", which has low wear, high accuracy, long accuracy retention time, and improves the service life of the mold.
◆ Adopting a forced thin oil circulation lubrication device: energy-saving, environmentally friendly, equipped with automatic alarm function, with better popularity and heat dissipation, and better lubrication effect.
◆ The crankshaft is made of high-strength alloy material 42CrMo, which is 1.3 times stronger than 45 steel and has a longer service life.
◆ The copper sleeve adopts tin phosphorus bronze ZQSn10-1, which has a strength 1.5 times higher than ordinary BC6 brass. It adopts a highly sensitive hydraulic overload protection device, which can effectively protect the service life of the punching machine and mold.
◆ Standard Japanese SMC pressure regulating valve, oil mist filter, and air filter.
◆ Standard touch screen and Siemens motor.
◆ Optional mold pad (air cushion).
