性能特點  Performance Features

◆ 采用高強度機身構造，變形量小，精度高。
◆ 采用OMPI氣動干式離合剎車器。
◆ 滑塊采用兩角六面導路，滑塊導軌采用“高頻淬火”十 “導軌研磨工藝”：磨損小、精度高、精度保持時間長、提高模具使用壽命。
◆ 曲軸采用高強度合金材質42CrMo，強度比45鋼提高了1.3倍，使用壽命更長。
◆ 銅套采用錫磷青銅ZQSn10-1，強度比普通BC6黃銅提高了1.5倍。
◆ 采用高靈敏液壓過載保護裝置，可有效保護沖床和模具使用壽命。
◆ 標配SMC調壓閥、油霧器、空氣過濾器。
◆ 可選配模墊（氣墊）。

◆ Adopting high-strength body structure, with small deformation and high accuracy.
◆ Adopting OMPI pneumatic dry clutch brake.
◆ The slider adopts a hexagonal guide path with two corners, and the slider guide adopts a "high-frequency quenching" and "rail grinding process", which has low wear, high accuracy, long accuracy retention time, and improved mold service life.
◆ The crankshaft is made of high-strength alloy material 42CrMo, which is 1.3 times stronger than 45 steel and has a longer service life.
◆ The copper sleeve adopts tin phosphorus bronze ZQSn10-1, which has a strength 1.5 times higher than ordinary BC6 brass.
◆ Adopting a highly sensitive hydraulic overload protection device can effectively protect the service life of the punching machine and mold.
◆ Standard SMC pressure regulating valve, oil mist filter, and air filter.
◆ Optional mold pad (air cushion).
