性能特點  Performance Features

◆ 機身構造采用（頂座+中臺身+底座）三部分組成，之后用補強桿固鎖連接為一體。
◆ 機身、滑塊高剛性（變形量）1/9000：變形小，精度保持時間長。
◆ 600噸以下沖床采用氣動濕式離合剎車器（一體式），800噸以上的沖床采用干式離合剎車器（分體式）。
◆ 滑塊采用四角八面導路，可承載較大的偏心負載，確保沖壓精度的長期、穩(wěn)定保持。
◆ 滑塊導軌采用“高頻淬火”十 “導軌研磨工藝”：磨損小、精度高、精度保持時間長、提高模具使用壽命。
◆ 采用強制稀油循環(huán)潤滑裝置：節(jié)能、環(huán)保、設有自動報警功能，具有更好的流行性及散熱性，潤滑效果更好。
◆ 曲軸采用高強度合金材質42CrMo，強度比45鋼提高了1.3倍，使用壽命更長。
◆ 銅套采用錫磷青銅ZQSn10-1，強度比普通BC6黃銅提高了1.5倍采用高靈敏液壓過載保護裝置，可有效保護沖床和模具使用壽命。
◆ 標配德國西門子觸摸屏、西門子電機。 可選配模墊（氣墊），可選配移動臺車。

◆ The body structure is composed of three parts (top seat, middle platform body, and base), and finally connected with a reinforcing rod to form a solid lock.
◆ The body and slider have high rigidity (deformation) of 1/9000: small deformation and long accuracy retention time.
◆ Punches below 600 tons use pneumatic wet clutch brakes (integrated), while punch presses above 800 tons use dry clutch brakes (split).
◆ The slider adopts a four corner and eight sided guide path, which can bear large eccentric loads, ensuring long-term and stable maintenance of stamping accuracy.
◆ The slide rail adopts the "high-frequency quenching" and "rail grinding process": low wear, high precision, long accuracy retention time, and improved mold service life.
◆ Adopting a forced thin oil circulation lubrication device: energy-saving, environmentally friendly, equipped with automatic alarm function, with better popularity and heat dissipation, and better lubrication effect.
◆ The crankshaft is made of high-strength alloy material 42CrMo, which is 1.3 times stronger than 45 steel and has a longer service life.
◆ The copper sleeve adopts tin phosphorus bronze ZQSn10-1, which has a strength 1.5 times higher than ordinary BC6 brass. It adopts a highly sensitive hydraulic overload protection device, which can effectively protect the service life of the punching machine and mold.
◆ Standard configuration: German Siemens touch screen and Siemens motor. Optional mold pad (air cushion) and optional mobile trolley.
